NCM M7
$2,499.00 CAD
$2,250.00 CAD
Shipping calculated at checkout.
Have a question?
NCM M7
Up to
32km/h
Up to
200km
X16 48V 500W
912WH
48V 19AH
Torque
Sensor
Das-Kit
C8
Das-Kit
48V 3A
Max torque
70Nm
HANDLEBAR
SUPPLIED WITH A HIGHOUTPUT POWER
SELLE EGRONOMIQUE
SPECIFICATION
| Bike Components |
| Frame | Alu. 6061, 27.5"*19 inches |
| Suspension Fork | Suntour, XCM-HLO-27.5, with hydraulic lock system |
| Brake | F/R: Das-Kit Hydraulic Disc Brakes, DK-100，F: 180mm rotor R: 180mm rotor |
| Freewheel | LY, 8 Speed, 11-32T, Silver |
| Tire | Schwalbe, Smart Sam, 27.5"*2.35, Black |
| Saddle | Selle Royal, Lookin-A200UR, Black |
| Stem | Promax, Alu.MA-471 |
| Crank | Das-Kit, 52T |
| Shifter | Shimano, Altus, R: SL-M315-8R, 8 Speed, BK |
| Rear Derailleur | Shimano, Acera, RD-M360 |
| Chain | KMC, Z8.3RB, Silver |
| Electric Components |
| Battery | Das-Kit, i7-4819, 48V 19AH, 912WH |
| Motor |
Das-Kit, X16, Rear drive motor, 48V 500W, 32KM/H |
| Controller |
Das-Kit, T7+, 48V 22A |
| Charger | Das Kit, 48V3A |
| Display | Das-Kit, C8, with USB |
| Front Light | DH007Plus, 48V, 70Lux |
| Weight |
| Net Weight (with battery) | 23kg |
| Battery Weight | 4.8kg |
| Total Weight (driver+bike) | 125kg |
Suitable for riders 170cm+ |
| Sizing my vary for each individual. Please refer to the stand over height in the chart below to find the best fit for you. |
27.5" |
|
| A Stand over height | 82 cm |
| B. Wheel base | 110 cm |
| C. Frame Size | 48 cm |
| D. Min/Max seat height | 87-105 cm |
| E. Reach | 39.8 cm |
| F. Overall length | 181.3 cm |
 Recommended Height
|
170 - 185 cm |
